Project Description
Well equipped Bell Helicopter 206B3 Jet Ranger with spray system available for immediate sale. Owner is accepting offers to purchase.
SOLD – 1980 Bell Helicopter 206B3 Jet Ranger – N158H
HELICOPTER INFORMATION |
|
| Year | 1980 |
| Manufacturer | Bell Helicopter |
| Model | 206B3 Jet Ranger |
| Price | Contact Us |
| Location | – |
| Serial Number | 2974 |
| Registration | N158H |
| Total Time | TTAF 20,774.20 Hrs |
| EQUIPMENT & ACCESSORIES | |
| Isolair Spray System | AirComm Bleed Air Heater with Defrost |
| Baggage Extender with Floor and Wall Protectors | Fuel Range Extender |
| External Facet Oil Filter | Position, Pulse and Landing Lights |
| Inlet Barrier Filter | Kaflex Drive Shaft |
| Crew and Pax Air Deflectors | Cabin Floor Protectors |
| Dual Caliper Rotor Brake Kit | Pre-flight Steps and Handle |
| Van Horn Tail Rotor Blades | AG NAV Guia |
| Auto Cal Flow Control | |
| AVIONICS | |
| Flight Instrument Group | Garmin GNC420 GPS/VHF |
| Bendix KY196A VHF | TFM-138B FM Radio |
| GTX330 Mode S Transponder | KMA-24H Audio Panel |
| SSD120 Altitude Encoder | ACK451 ELT |
| COMPONENT STATUS | ||
| Component | Hours Remaining | OH/Insp./RT |
| Engine: | ||
| Turbine | 714 | OH |
| Wheel 1 | 739 | RT |
| Wheel 2 | 739 | RT |
| Wheel 3 | 1765 | RT |
| Wheel 4 | 1765 | RT |
| Compressor | 118 | Insp. |
| Governor | 1802 | OH |
| Fuel Pump | 1165 | OH |
| Fuel Nozzle | 925 | OH |
| Fuel Control | 300 | OH |
| Bleed Valve | 1125 | OH |
| Components: | ||
| MR Hub assy | 1074 | OH |
| MR Blade 1 | 2327 | RT |
| MR Blade 2 | 2327 | RT |
| MR Mast assy | 1202 | OH |
| MR Transmission | 1044 | OH |
| MR Driveshaft assy | 268 | OH |
| Swashplate assy | 794 | OH |
| TR Gearbox assy | 5100 | OH |
| TR Hub assy | 1149 | OH |
| TR blade 1 | 3649 | RT |
| TR blade 2 | 3649 | RT |
| Freewheeling assy | 3000 | OH |
| Servo 1 | 1163 | OH |
| Servo 2 | 163 | OH |
| Servo 3 | 366 | OH |
| Hyd Pump | 3059 | OH |
| Starter Generator | 728 | OH |
| The Bell Helicopter 206B3 Jet Ranger | |
| Performance | Dimensions |
| Cruise speed – 120 knots | Size (feet) – 33.4 L x 7.6 W x 9.4 H |
| Range – 374 Nautical miles | Empty weight – 2,000 lbs. |
| Ceiling – 13,500+ feet | Max gross weight – 3,350 lbs. |
| Rate of Climb – 1,350 feet / minute | Fuel capacity – 91 gallons / 610 lbs. |
| Cabin | Lift |
| Crew (typical) – 1 or 2 | External load – 1,500 lbs. |
| Passenger (typical) – 3 or 4 | Internal load – 1,487 lbs. |
| Storage – 22 cu ft. | |
